Insulation material | PPE/PA |
Rated voltage | 1000V DC |
Rated current(With Diode) | 10A (Diode Rated Current 15A) |
Rated current(Without Diode) | 30A |
Contact resistance | ≤0.25mΩ |
Test voltage | 6KV(50Hz,1min) |
Contact material | Copper,Tin plated |
Degree of protection | IP67 |
Safety degree | II |
Flame class | UL94-V0 |
Insertion force/Withdrawal force | ≤50N/≥50N |
overvoltage category/Pollution degree | CATIII/2 |
Ambient temperature range | -40℃...+85℃(IEC) |
Connection mode | Crimp connection |
Suitable cable cross sections | 2.5~6m㎡/14~10AWG |
Upper limiting temperature | 110℃(IEC) |
4D0
4D1
4D2
4D3
The PV 4.0 Diode Connector is engineered to provide reliable, efficient, and secure connections for your solar power systems. With its durable construction, medium voltage rating, and integrated diode, this connector ensures optimal performance and safety in demanding outdoor environments. Choose our PV 4.0 Diode Connector for a dependable solution in your renewable energy projects.
